High speed mixer
|
|
| Product Name：High speed mixer |
| Category：SHR series high speed mixer |
| Product Name：1939 |
| Date：2014/11/18 16:46:22 |
| Inquiry |
|
Products
The main technical parameters of high-speed mixer:| Model / parameter | The total volume（L） | Effective volume（L） | Motor and heating power（KW） | Spindle speed（RPM） | Dimensions L × W × H | Heating | Discharge mode | | | | | | | | Since the friction | Manual | | SHR-10A | 10 | 7 | 3 | 2000 | 1200×300×830 | | SHR-25A | 25 | 20 | 5.5 | 1440 | 1200×350×850 | | SHR-50A | 50 | 35 | 7/11/3 | 750/1500 | 2100×700×1100 | Electric heating /
Since the friction | Pneumatic | | SHR-100A | 100 | 75 | 14/22/6 | 650/1300 | 2100×800×1510 | | SHR-200A | 200 | 150 | 30/42/9 | 475/950 | 2400×850×1580 | | SHR-300A | 300 | 225 | 40/55/9 | 475/950 | 2800×1080×1680 | | SHR-500A | 500 | 375 | 47/67/12 | 430/860 | 3060×1150×1880 | | SHR-800A | 800 | 600 | 83/110/15 | 370/740 | 3385×1380×2750 | | SHR-1000A | 1000 | 750 | 110/160/28 | 325/650 | 3460×1140×2900 | Electric heating /
Since the friction | Pneumatic | | SHR-200C | 200 | 150 | 30/42 | 650/1300 | 2545×900×1700 | | SHR-300C | 300 | 225 | 47/67 | 475/950 | 2800×1080×1680 | | SHR-500C | 500 | 375 | 83/110 | 500/1000 | 3060×1150×1880
|
|
